Input Power: 105-135VAC, 50/60Hz, 35W exclusive of load (220V AC
or 240V AC option)
Operating Temperature: -10° F to 130° F (-23° C to 55° C)
Offset/Preset: Programmable “0” to full scale
Number of Programmable Channels: 8
Input/Output
Inputs:
Position input Linear Transducer, Program Enable |
Outputs:
8 PLS outputs
Modules:
Cam modules: 8 outputs each. NPN sink transistor
Outputs: Electrical Characteristics:
NPN Sink Transistor Output:
Energized: Transistor ON; 1.1V drop@100mA
De-energized: Transistor OFF; 01mA leakage ©50VDC |
