Input Power:
     AC:  105-135 VAC, 50/60 Hz (220 VAC, 50 Hz optional)
     DC:  10-28 VDC (required only if sourcing a total of more
     than 100 mA with PNP (sourcing) card)
Operating Temperature:  -10°F to +130°F (-23°C to +55
     °C)
Speed:  0 to 2,000 rpm
Max. Phase Shift:  V @ 1000 rpm
Resolution:  1° @ 1800 rpm
Number of Outputs:  4,8,12, or 16

Built-in Resolver (option):
     Frequency:  2,250 Hz
     Input Voltage:  1.88 V
     Input Current:  6 mA
     Input Power:  6.5 mW
     Rotor Impedance with Stator Open Circuit Zro:
     180 + j256 OHMS
     DC Resistance (Rotor):  18.3 OHMS
     Output Voltage (Stator):  2.63 V +5%
     Transformation Ratio:  1:400
Built-in pulse generating Disc:
     60 ppr (3° slots), Replaces cam at position 1
